Quick answer
What homeowners need to know
Waterproofing planning coordinates substrate, junctions, penetrations, falls, product system, installer responsibilities and protection before finishes are applied.
Keep product and installation records with progress photos and any required inspection documentation.
Key takeaways
- Confirm the waterproofing system and installer before work begins.
- Pay closest attention to junctions and penetrations, because that is where failures usually begin.
- Ask for progress photos of the membrane before tiling starts.
- A bathroom is a coordinated wet-area system involving waterproofing, falls, plumbing and ventilation.
Bathroom renovation
Bathroom waterproofing planning before the tiles go on
Confirm the waterproofing system and installer before work begins. A membrane system is designed to work with specific primers, reinforcing tapes, sealants and substrates, and mixing brands can affect performance. Ask who will apply it, whether they are trained in that system and what substrate preparation it needs. Write the system name into the scope so substitutions need your approval.
Pay closest attention to junctions and penetrations, because that is where failures usually begin. Wall-to-floor corners, the shower waste, mixer penetrations, niche edges and shower screen fixings all need detailing. Ask for the mixer body and waste to be installed and tested before the membrane goes on, so the waterproofer can seal around their final positions rather than guessing.
Ask for progress photos of the membrane before tiling starts. Photos showing coverage at corners, upstands, penetrations and the floor waste give you a record if questions arise later. Keep them with the product data and installer details. Where a building consent applies, check whether the waterproofing stage needs a council inspection and make sure it is booked before the membrane is covered.
Scope before solutions
Decisions to make before committing
Settle these points before an idea becomes an order, contract or construction instruction.
Keep product and installation records with progress photos and any required inspection documentation.
waterproofing and substrate condition
amount of tiling and fixture specification
plumbing relocation, ventilation and hidden moisture repair
Practical sequence
A step-by-step planning process
- 01
Define the exact outcome you need and how success will be checked.
- 02
Inspect moisture, substrate, plumbing, ventilation and access before confirming the scope.
- 03
Set the layout and choose fixtures using verified dimensions and service requirements.
- 04
Document waterproofing, lining, tiling, ventilation, electrical and finishing responsibilities.
- 05
Plan inspections, curing time, commissioning and handover records before work begins.

Cost and time
How to build a more reliable budget and programme
A fixed price or completion date needs a measured scope and a site visit. Use qualified practitioners for restricted plumbing, electrical and waterproofing work, and confirm consent requirements for the actual alteration.
Use the calculator, then request a site-specific assessment.
Risk control
Common mistakes to avoid
- Mixing unverified system components or damaging the membrane during later work can compromise performance.
- treating waterproofing as an isolated trade detail
- selecting fixtures that conflict with door, shower or cleaning clearances
Accuracy and compliance
Use current official information
Primary sources used for this guide
- Building and renovation projectsAuckland Council
- Check if you need consentsBuilding Performance (MBIE)
- Home renovation and repairConsumer Protection New Zealand
Common questions
Frequently asked questions
When should bathroom waterproofing be done?
Waterproofing is applied after framing repairs, linings, substrate preparation and rough-in plumbing are complete, and before tiling. The shower waste and mixer bodies should be in their final positions so the membrane can be sealed around them. The membrane must cure as the manufacturer instructs before any tiles are laid.
What are the signs of a failing shower waterproofing membrane?
Signs include cracked or crumbling grout, loose or hollow-sounding tiles, mould around the shower base, swollen skirting or door frames, and stains or musty smells in rooms next to the bathroom. If you notice these, stop using the shower and have it inspected, because water may already be reaching the framing.
Can I tile over existing tiles in a bathroom?
Tiling over old tiles is rarely suitable in a shower or wet area, because the new waterproofing system needs a compatible, sound substrate. It can also raise floor levels and change falls to the waste. Ask your contractor and the tile and membrane manufacturers whether the existing surface can be used before planning a tile-over.
